CYBENETICS LTD Syrou 6, Latsia, 2231, Nicosia Cyprus
MSI MAG A650GL
Serial Number
Lab IDMS65002422
  • Report: 24PS2422A
  • Receipt Date: Apr 4, 2024
  • Test Date: Apr 19, 2024
  • Report Date: Apr 23, 2024
115V230V
Efficiency Rating
115V230V
Noise Rating
Aristeidis Bitziopoulos, Laboratory General Manager

General Information

DUT Information

BrandMSI
Manufacturer (OEM)CWT
SeriesMAG
Model NumberMAG A650GL
Serial Number
DUT NotesCWT GPX PLATFORM

DUT Specifications

Rated Voltage (Vrms)100-240
Rated Current (Arms)10
Rated Frequency (Hz)47-63
Rated Power (W)650
TypeATX12V
Cooling120mm Fluid Dynamic Bearing Fan
(DF1202512FDHN)
Semi-Passive Operation✗
Cable DesignFully Modular

Power Specifications

Rail3.3V5V12V5VSB-12V
Max. PowerAmps2020542.50.3
Watts10064812.53.6
Total Max. Power (W)650

Test Equipment

Electronic Loads Chroma 63601-5 x2
Chroma 63600-2
63640-80-80 x10
63610-80-20
AC Sources Chroma 6530, APM SP300VAC4000W-P
Power Analyzers RS HMC8015, N4L PPA1530, N4L PPA5530
Oscilloscopes Picoscope 4444, Rigol DS7014, Siglent SDS2104X PLUS
Sound Analyzer Bruel & Kjaer 2270 G4
Microphone Bruel & Kjaer Type 4955-A
Temperature Logger Picoscope TC-08
Tachometer UNI-T UT372
Multimeters Keysight 34465A, Keithley 2015 - THD
UPS FSP Champ Tower 3kVA, CyberPower OLS3000E 3kVA
Isolation Transformer 4kVA
Testing Methodology Cybenetics PSU Test Protocol

Cables and Connectors

Modular Cables
Description Cable Count Connector Count (Total) Gauge In Cable Capacitors
ATX connector 20+4 pin (600mm) 1 1 18AWG No
4+4 pin EPS12V (750mm) 2 2 18AWG No
6+2 pin PCIe (600mm+150mm) 2 4 18AWG No
SATA (500mm+150mm+150mm) 2 6 18AWG No
4-pin Molex (500mm+150mm+150mm) / FDD (+155mm) 1 3 / 1 18-20AWG No

Test Results

Temperature & Compliance Info

Temperature Range (°C /°F)30-32 / 86-89.6
ErP Lot 3/6 Ready✓
(EU) No 617/2013 Compliance✓

Performance Summary 115V

Hold-Up Time & Power Ok Signal

Hold-Up Time (ms)14.5
AC Loss to PWR_OK Hold Up Time (ms)13.3
PWR_OK Inactive to DC Loss Delay (ms)1.2

Vampire Power

Tables 115V

Detailed Results
Average Min Limit Min Max Limit Max Result
Mains Voltage RMS: 115.06 V 115.03 V 113.85 V 115.11 V 116.15 V PASS
Mains Frequency: 60.00 Hz 59.99 Hz 59.40 Hz 60.01 Hz 60.60 Hz PASS
Mains Voltage CF: 1.416 1.415 1.340 1.418 1.490 PASS
Mains Voltage THD: 0.13 % 0.09 % N/A 0.19 % 2.00 % PASS
Real Power: 0.043 W 0.012 W N/A 0.062 W N/A N/A
Apparent Power: 10.235 W 10.148 W N/A 10.336 W N/A N/A
Power Factor: 0.006 N/A N/A N/A N/A N/A

Efficiency Graph

115V

INFO

This graph depicts the PSU`s efficiency throughout its entire operational range. For the generation of the efficiency and noise graphs we set our loaders to auto mode through our custom-made software before trying thousands of possible load combinations

Noise Graph

115V

INFO

The PSU`s noise in its entire operational range and under 30-32 °C ambient is depicted in this graph. The X axis represents the load on the +12V rail(s) while the Y axis is the load on the minor rails

Indicative Performance

Efficiency under high ambient temperature

INFO

The PSU`s efficiency under high ambient temperatures with 115V and 230V input. For this graph the results of the 10-110% load regulation table are used

5VSB Efficiency

INFO

This graph depicts the efficiency levels of the 5VSB rail with 115V and 230V input

5VSB Efficiency (ERP LOT 3/6 & CEC) 115V

Test # 5VSB DC/AC (Watts) Efficiency PF/AC Volts
1 0.045A 0.23W 68.55% 0.033
5.113V 0.335W 114.94V
2 0.09A 0.46W 74.842% 0.06
5.111V 0.614W 114.94V
3 0.55A 2.804W 80.762% 0.263
5.099V 3.472W 114.92V
4 1A 5.087W 79.068% 0.352
5.087V 6.434W 114.91V
5 1.5A 7.61W 79.045% 0.407
5.073V 9.627W 114.91V
6 2.5A 12.613W 76.884% 0.462
5.046V 16.406W 114.9V

Supplementary Tests (For Reference)

Typical Load Tests 115V

Test 12V 5V 3.3V 5VSB DC/AC (Watts) Efficiency Fan Speed (RPM) PSU Noise (dB[A]) Temps (In/Out) PF/AC Volts
10% 3.612A 1.994A 1.981A 0.985A 64.997 85.059% 1139 29.5 40.05°C 0.955
12.016V 5.015V 3.331V 5.075V 76.417 44.33°C 114.88V
20% 8.248A 2.992A 2.974A 1.185A 129.926 88.73% 1144 29.6 40.9°C 0.973
12.007V 5.012V 3.328V 5.062V 146.428 45.58°C 114.86V
30% 13.240A 3.493A 3.472A 1.387A 194.925 89.999% 1146 29.7 41.33°C 0.978
11.999V 5.01V 3.326V 5.048V 216.587 46.33°C 114.84V
40% 18.247A 3.993A 3.971A 1.589A 260.007 90.248% 1145 29.7 41.65°C 0.981
11.991V 5.009V 3.325V 5.035V 288.104 47.27°C 114.82V
50% 22.908A 4.994A 4.967A 1.793A 324.998 90.057% 1154 29.9 42.36°C 0.984
11.982V 5.006V 3.322V 5.021V 360.878 48.45°C 114.8V
60% 27.520A 5.995A 5.966A 1.997A 389.308 89.551% 1156 29.9 42.87°C 0.983
11.973V 5.004V 3.319V 5.007V 434.733 49.39°C 114.77V
70% 32.221A 6.999A 6.966A 2.203A 454.611 88.678% 1706 40.8 43.24°C 0.982
11.965V 5.002V 3.316V 4.992V 512.653 50.3°C 114.74V
80% 36.930A 8.001A 7.968A 2.308A 519.44 87.862% 2200 46.2 43.65°C 0.982
11.956V 4.998V 3.313V 4.981V 591.203 51.68°C 114.72V
90% 42.045A 8.505A 8.456A 2.414A 584.846 87.146% 2407 48.5 44.35°C 0.985
11.948V 4.996V 3.311V 4.971V 671.109 53.4°C 114.69V
100% 47.102A 9.009A 8.975A 2.52A 649.578 86.417% 2409 48.5 44.63°C 0.987
11.940V 4.994V 3.309V 4.959V 751.672 54.79°C 114.67V
110% 51.899A 10.016A 10.073A 2.525A 715.009 85.41% 2411 48.6 42.81°C 0.987
11.931V 4.991V 3.306V 4.951V 837.152 53.72°C 114.65V
CL1 0.115A 12.044A 11.985A 0A 101.288 83.25% 1153 29.9 40.46°C 0.968
12.001V 4.998V 3.313V 5.085V 121.669 49.93°C 114.86V
CL2 0.115A 19.998A 0A 0A 101.338 80.738% 1152 29.9 41.14°C 0.969
12.004V 4.998V 3.326V 5.09V 125.515 50.57°C 114.87V
CL3 0.115A 0A 19.943A 0A 67.394 75.329% 1127 29.1 40.12°C 0.959
12.003V 5.01V 3.31V 5.091V 89.466 50.2°C 114.89V
CL4 54.354A 0A 0A 0A 649.495 87.568% 2400 48.4 42.85°C 0.987
11.949V 5.014V 3.328V 5.037V 741.707 52.11°C 114.68V

The results above are not used in the certification process

Light Load Tests 115V

Test 12V 5V 3.3V 5VSB DC/AC (Watts) Efficiency Fan Speed (RPM) PSU Noise (dB[A]) Temps (In/Out) PF/AC Volts
20W1.236A0.498A0.495A0.196A19.99570.878%108928.036°C0.842
12.014V5.02V3.336V5.104V28.2139.05°C114.9V
40W2.720A0.697A0.693A0.294A39.99581.057%112429.037.88°C0.924
12.016V5.018V3.335V5.099V49.34241.19°C114.89V
60W4.204A0.897A0.891A0.393A59.99585.178%112829.138.19°C0.953
12.018V5.018V3.334V5.094V70.43441.74°C114.88V
80W5.685A1.096A1.089A0.491A79.93787.07%113429.439.59°C0.959
12.015V5.017V3.333V5.088V91.80843.44°C114.88V

The results above are not used in the certification process

Ripple Measurements 115V

Test12V5V3.3V5VSBPass/Fail
10% Load30.01mV17.11mV17.14mV18.11mVPass
20% Load35.95mV17.01mV16.88mV18.52mVPass
30% Load34.93mV17.11mV17.24mV20.82mVPass
40% Load25.31mV12.92mV12.23mV17.03mVPass
50% Load17.48mV13.39mV12.58mV16.88mVPass
60% Load16.61mV13.23mV13.35mV18.82mVPass
70% Load19.63mV13.74mV13.50mV16.88mVPass
80% Load20.24mV14.61mV14.99mV17.08mVPass
90% Load21.16mV16.40mV15.09mV18.21mVPass
100% Load33.10mV16.67mV15.37mV18.06mVPass
110% Load34.67mV17.56mV16.06mV19.82mVPass
Crossload144.66mV15.65mV17.56mV15.19mVPass
Crossload238.41mV21.76mV12.74mV15.14mVPass
Crossload335.39mV12.82mV17.60mV14.37mVPass
Crossload432.97mV15.80mV14.20mV18.44mVPass

The results above are not used in the certification process

MSI MAG A650GL

Top side
Power specifications label
All data and graphs included in this test report can be used by any individual on the following conditions:
› It should be mentioned that the test results are provided by Cybenetics
› The link to the original test results document should be provided in any case
Cybenetics offers the ETA and Lambda voluntary certification programs, through which the efficient and silent power supplies are promoted
